The scraper pipe, the core conveying component of the scraper suction hopper, is manufactured from high-strength, wear-resistant alloy steel and consists primarily of the following components:
● Main body: Spirally welded steel pipe, typically 500-1200mm in diameter, with a wear-resistant lining on the inner wall.
● Universal joint: A special hinged structure allows for a ±15° swing angle.
● Telescopic sleeve: A hydraulically driven telescopic section with an adjustable range of 2-3 meters.
● Wear-resistant flange: Specially hardened at the inlet and outlet ends for a service life of up to 8,000 operating hours.

Options:

The suction port slider assembly is used to Key components for data collection include three functional modules:
Guide rail system:
Double V-shaped wear-resistant guide rails, HRC 58-62 hardness
Self-lubricating copper-based composite sliders
Straightness error ≤ 0.1 mm/m

Hydraulic drive unit:
Double-acting hydraulic cylinder (Ø 200 mm)
Maximum thrust 120 kN
Displacement accuracy ± 2 mm

Adaptive suction port assembly:
Adjustable lip (adjustment range 150 mm)
Wear-resistant grille (opening rate 65%)
Anti-clogging vibrator (frequency 25 Hz)
